 Intro

Below you can find the source for the Indices-Comparison. Copy and paste it in your html code and modify it according to your needs.

--------------- Source Start ---------------
<HEAD>
<SCRIPT TYPE="text/javascript" LANGUAGE="JavaScript">
<!--

function ochart_onload()
{
//window.alert("risnet");
//  oChart.style.display="";
}

// end -->
</SCRIPT>
</HEAD>

<BODY>
<SCRIPT>
<!--
function B1_onclick() {
	var sLine;
	var s = document.risnet.Ric2.options[document.risnet.Ric2.selectedIndex].value;
	if (s =="") {
		sLine=document.risnet.Ric.options[document.risnet.Ric.selectedIndex].value;
	}
	else {
		sLine=document.risnet.Ric.options[document.risnet.Ric.selectedIndex].value+"&RIC2="+s;
	}
	var z=document.forms[0].Samples.value;
	sLine=sLine+"&Height=250&Width=400&Period=Daily&Legend=True&Cadre=FALSE&Samples=" + z;
	if (document.risnet.chkVolume.checked) {
		sLine = sLine + "&Volume=True";
	}
	if (document.risnet.chkLegend.checked) {
		sLine = sLine + "&Legend=True";
	}
	if (!document.risnet.chkAverage.checked) {
		sLine=sLine+"&Average=True&AvgColor=2741810";
	}
	sLine=sLine+"&LineColor=8388608&LineColor2=255&BGColor=15790325";
	document.risnet.oChart.src = "http://194.106.234.14/scripts/getChart.exe?RIC=" + sLine;
}


// end -->
</SCRIPT>
<FORM NAME="risnet">
<TABLE ALIGN="center" WIDTH="550" bgcolor="#001468">
	<TR VALIGN="top">
		<TD WIDTH="100%">
			<FONT SIZE="2" FACE="Arial" COLOR="white">
				<B><CENTER>INDIZES COMPARISON</CENTER></B>
			</FONT>
		</TD>
	</TR>
</TABLE>


<TABLE ALIGN="center" WIDTH="550" BGCOLOR="#001468">
	<TR VALIGN= "top">
		<TD>
			<FONT SIZE="2" FACE="Arial" COLOR="white">
				Indizes Name
				<BR>
				<SELECT NAME="Ric" ID="Ric">
					<OPTION VALUE=".ATX">AustrianTradedIndex
					<OPTION VALUE=".GDAXI">DeutscherAktienIndex
				</SELECT>
				<INPUT ID="chkVolume" TYPE="checkbox" VALUE="">Volume
				<BR>
				<INPUT ID="chkAverage" TYPE="checkbox" VALUE="True">Durchschnitt
				<BR><BR>
				Vergleichen mit: Tagezurück
				<BR>
				<SELECT NAME="Ric2" ID="Ric2">
					<OPTION VALUE=".ATX">AustrianTraded Index
					<OPTION VALUE=".GDAXI">DeutscherAktienIndex
				</SELECT>
				<BR>
				<INPUT TYPE="Text" SIZE="14" ID="Samples" NAME="Samples" value="90">
				<INPUT TYPE="checkbox" ID="chkLegend" VALUE="" CHECKED="true">
				<BR>
				Legende
				<BR><BR><BR></P>
				<DIV ALIGN="center">
					<INPUT TYPE="button" NAME="B1" VALUE="Vergleich" onClick=
					"B1_onclick();">
					<BR>
				</DIV>
			</FONT>
		</TD>
	</TR>
</TABLE>
<BR>
<CENTER>
<IMG NAME="oChart" src="images/blank.gif">
</FORM>
</BODY>
--------------- Source End -----------------
INDICES COMPARISON
Indizes Name
   Volume   Average

Vergleichen mit:                         Days back
      Legend

You have to use the following tag in the HTML-source code to display the Chart:

<img src="http://194.106.234.14/scripts/getChart.exe?parameters">

The parameters for getChart.exe are:

RIC: Ric (eg EUR=)

RIC2: 2nd ric to be able to compare... (No volume support)

Samples: Number of samples back from today.

Period: Period, can have the values 'Daily','Weekly','Monthly'

Height: Height of the image (for close price). If not specified than the default is 80.

VolumeHeight: Height of the volume section of the image. If not specified uses the 1/2 size of the original height.

Width: Width of the image. If not specified default is 150.

Average: Average line for 1st RIC. True/False. If not specified default value is TRUE.

BGColor: Background color for the image. Takes numerical values. (e.g. 16777215 for white or 0 for black). Default is white.

LineColor: Same as BGColor. Line color of the RIC.

LineColor2: Same as BGColor. Line color of the RIC.

AvgColor: Color of the average line (numerica).

Volume: TRUE or FALSE. Default is false. Recommended not to use if you choose 2 RICs' to be compared.

VolumeColor: Color of the volume (numerical).

FontColor: Color of the fonts (Numerical).

Cadre: TRUE or FALSE. If not specified it uses FALSE. This option displays or hides the tick labels (Dates and prices). Useful if you're generating a small image.

Legend: TRUE or FALSE. If not specified the default value is false. Useful if you're comparing 2 RICs and add the Average function.
